Customizable Rexroth PGH4-30 040RE11VU2 Servo Motor For Your Industrial Needs

Technical Specifications

• Brand: Bosch Rexroth
• Model: PGH4-30 040RE11VU2
• Material Number: R901147103
• Displacement: 40.1 cm³/rev
• Maximum Operating Pressure: 350 bar
• Flow Rate: Up to 120 liters/min at 3000 RPM
• Shaft Design: Cylindrical shaft with fitting key, DIN 6885
• Mounting Flange: SAE 2-hole
• Seals: FKM (fluorocarbon)
• Weight: Approximately 15 kg
• Dimensions: 150 mm (L) x 73 mm (W) x 134 mm (H)
• Operating Noise: Low noise operation, suitable for environments where noise reduction is important

Features

• Fixed Displacement: Ensures consistent flow.
• Low Noise Operation: Suitable for noise-sensitive environments.
• Low Flow Pulsation: Provides smooth operation.
• High Efficiency: Even at low speed and viscosity, due to sealing gap compensation.
• Robust Design: Durable construction with a cast iron housing.
• Versatile Applications: Suitable for a wide range of industrial uses.

Applications

• Machine Tools: Provides precise hydraulic power for machine tools.
• Steel and Metallurgy: Used in hydraulic systems in steel plants.
• Cement Plants: Ensures reliable hydraulic power for cement manufacturing equipment.
• Construction Machinery: Provides consistent hydraulic power for construction equipment.
