Rexroth PGH5-30 250RE07VE4 Servo Motor for High-Performance Applications

Product Overview

Technical Specifications

• Brand: Bosch Rexroth
• Model: PGH5-30 250RE07VE4
• Material Number: R901147128
• Frame Size: 5
• Displacement: 250.5 cm³/rev
• Maximum Operating Pressure: 350 bar
• Flow Rate: Up to 751 liters/min at 3000 RPM
• Shaft Design: Cylindrical shaft with fitting key, ISO 3019-2
• Mounting Flange: 4-hole mounting flange according to ISO 3019-2 and VDMA 24560
• Seals: FKM (fluorocarbon)
• Weight: Approximately 52 kg
• Dimensions: 299 mm (L) x 150 mm (W) x 283 mm (H)
• Features:
  • Fixed displacement ensures consistent flow.
  • Low operating noise, making it suitable for noise-sensitive environments.
  • Low flow pulsation for smooth operation.
  • High efficiency even at low speed and viscosity due to sealing gap compensation.
  • Suitable for a wide range of viscosities and speeds.

Applications

• Plastic Processing Machines: Suitable for variable speed drives with high load cycle numbers.
• Presses: Ensures reliable hydraulic power for pressing operations.
• Casting Machines: Ensures consistent hydraulic power for casting processes.
• Hydraulic Systems: Ideal for various hydraulic equipment requiring high flow rates and pressures.
