SUN Cartridge Valve CXHA-XZN For Performance And Low Leakage High Pressure And Corrosion Resistant

SUN Cartridge Valve CXHA-XZN For Performance And Low Leakage High Pressure And Corrosion Resistant
SUN Cartridge Valve CXHA-XZN For Performance And Low Leakage High Pressure And Corrosion Resistant SUN Cartridge Valve CXHA-XZN For Performance And Low Leakage High Pressure And Corrosion Resistant

Large Image :  SUN Cartridge Valve CXHA-XZN For Performance And Low Leakage High Pressure And Corrosion Resistant

Product Details:
Place of Origin: American
Brand Name: SUN
Certification: cc
Model Number: CXHA-XZN
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: RMB/1000-10000/PC
Packaging Details: wooden case/carton
Delivery Time: 3days
Payment Terms: T/T
Supply Ability: 10PCS/days
Contact Now

SUN Cartridge Valve CXHA-XZN For Performance And Low Leakage High Pressure And Corrosion Resistant

Description
Brand: SUN Model: CXHA-XZN
Cavity: T-16A Series: 3
Capacity: 80 Gpm Maximum Operating Pressure: 5000 Psi
Maximum Valve Leakage At 110 SUS: 1 Drops/min. Valve Hex Size: 1 1/4 In.
Highlight:

corrosion resistant hydraulic relief valve

,

corrosion resistant mechanical hydraulic valve

SUN Cartridge Valve CXHA-XZN
High Performance, Low Leakage Valve for High Pressure and Corrosive Environments
Product Specifications
Attribute Value
Brand SUN
Model CXHA-XZN
Cavity T-16A
Series 3
Capacity 80 gpm
Maximum Operating Pressure 5000 psi
Maximum Valve Leakage at 110 SUS 1 drops/min.
Valve Hex Size 1 1/4 in.
Product Description

The SUN CXHA-XZN cartridge valve is a free-flow, nose-to-side check valve designed as an on/off circuit component that allows free flow from the inlet (port 1) to the outlet (port 2) while blocking reverse flow.

  • Extremely low leakage rates with maximum leakage less than 1 drop per minute (0.07 cc/min)
  • Handles pressures up to 5000 psi (350 bar) at ports 1 and 2
  • EPDM seals for use with phosphate ester fluids (not compatible with petroleum-based fluids)
  • Corrosion-resistant options available (identified by /AP or /LH suffix)
  • Sun floating style construction minimizes internal binding from installation torque or machining variations
Technical Details
Mounting Style Threaded or slip-in
Pilot Pressure Range 100-300 PSI
Port Type NPTF
Cavity T-11A
Solenoid Tube Diameter 0.75 in.
Dimensions 1.5 x 1.5 x 2.5 inches
SUN Cartridge Valve CXHA-XZN For Performance And Low Leakage High Pressure And Corrosion Resistant 0
Frequently Asked Questions
Do you accept small orders?
Yes, we accept small orders. Please contact us for details.
Can you ship to my country?
Yes, we can ship worldwide. We can arrange shipping if you don't have your own forwarder.
What are your payment terms?
We accept T/T, LC at sight, or 100% full payment.
What is your production lead time?
Typically 15 days for MOQ quantities, depending on product and order size.
When can I expect a quotation?
We typically respond within 24 hours. For urgent requests, please call or note in your email.
