AVENTICS 3460565500 Electro-Pneumatic Regulating Valve Stainless Steel Reliability

AVENTICS 3460565500 Electro-Pneumatic Regulating Valve Stainless Steel Reliability
AVENTICS 3460565500 Electro-Pneumatic Regulating Valve Stainless Steel Reliability AVENTICS 3460565500 Electro-Pneumatic Regulating Valve Stainless Steel Reliability AVENTICS 3460565500 Electro-Pneumatic Regulating Valve Stainless Steel Reliability

Large Image :  AVENTICS 3460565500 Electro-Pneumatic Regulating Valve Stainless Steel Reliability

Product Details:
Place of Origin: Germany
Brand Name: AVENTICS
Certification: cc
Model Number: 3460565500
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: RMB/100-10000/PC
Packaging Details: wooden case/carton
Delivery Time: 3 work days
Payment Terms: T/T
Supply Ability: 10PCS/days
Contact Now

AVENTICS 3460565500 Electro-Pneumatic Regulating Valve Stainless Steel Reliability

Description
Seal Material: Nitrile, Viton, Or EPDM Port Size: 1/4
Certifications: CE, ISO, Or UL Mounting Style: Inline Or Manifold
Material: Metal Body Material: Aluminum, Brass, Or Stainless Steel
Pressure Rating: Up To 5000 Psi Temperature Range: -20°F To 200°F
Highlight:

stainless steel hydraulic relief valve

,

stainless steel mechanical hydraulic valve

,

metal hydraulic relief valve

AVENTICS 3460565500 Electro-Pneumatic Regulating Valve Stainless Steel Reliability
Product Specifications
Attribute Value
Seal Material Nitrile, Viton, or EPDM
Port Size 1/4
Certifications CE, ISO, or UL
Mounting Style Inline or manifold
Material Metal
Body Material Aluminum, Brass, or Stainless Steel
Pressure Rating Up to 5000 psi
Temperature Range -20°F to 200°F
Flow Rate Up to 100 GPM
Application Industrial, Agricultural, or Construction
Type Mechanical
Function Hydraulic Control
Size Various sizes available
Valve Type 2-way, 3-way, or 4-way
Product Features
High-Precision Control and Dynamic Response
  • Electronically controlled proportional valve technology with real-time feedback control
  • Control accuracy of ±0.5% for precision pressure regulation
  • PWM control mode with millisecond-level response for high-frequency dynamic regulation
Integrated Design and Multi-Functional Adaptation
  • Integrated electronic control module and pneumatic control valve body
  • Supports analog (4-20mA) and digital signal input
  • Compatible with PLC and DCS control systems
  • Optional intelligent valve positioners for remote air-open/air-close mode switching
Safety, Reliability and Environmental Resistance
  • Fluororubber seals and corrosion-resistant materials (stainless steel components)
  • Operates in temperatures from -25℃ to 60℃
  • Maintains valve position during failures to prevent system risks
  • Available explosion-proof models (Ex certification) for hazardous environments
Energy Efficiency and Maintenance
  • Low flow resistance design reduces energy consumption
  • Solenoid valve life exceeds 30 million cycles
  • Modular structure for quick maintenance and diaphragm replacement
Installation and Usage Guidelines
Installation Specifications
  • Must be installed vertically (special inclination requires support frame)
  • Solenoid valve wiring port must face upward to prevent moisture accumulation
  • Thoroughly clean pipelines before installation to prevent valve core blockage
  • Reset handwheel to neutral position after debugging
Medium and Working Condition Adaptation
  • For particle-containing or viscous media, pre-install filters (≤40μm recommended)
  • Add pressure reducing valve before the valve to stabilize pressure
  • For ambient temperatures exceeding 60℃, install heat dissipation or thermal insulation
Maintenance and Inspection
  • Regularly check seals using soapy water or pressure gauge fluctuations
  • Empty residual pipeline pressure after shutdown
  • Apply anti-rust oil and block ports for long-term shutdown
Electronic Control System Management
  • Electrical connections must comply with explosion-proof specifications
  • Use shielded signal lines to prevent electromagnetic interference
  • Maintain input voltage within ±10% of rated value to prevent coil burnout
Emergency and Backup Measures
  • Configure bypass pipeline for high-risk conditions
  • Maintain gas source pressure at 6.2kg/cm²
  • Control oil content at 0-5mg/m³ to extend service life
AVENTICS 3460565500 Electro-Pneumatic Regulating Valve Stainless Steel Reliability 0
Frequently Asked Questions
Q: Do you accept small orders?
A: Yes, we accept small orders. Please contact us for more details.
Q: Can you ship to my country?
A: Yes, we can ship worldwide. If you don't have your own forwarder, we can assist.
Q: What are your payment terms?
A: We accept T/T, LC at sight, or 100% full payment.
Q: What is your production lead time?
A: Lead time depends on product and quantity. Typically 15 days for MOQ quantities.
Q: When can I get a quotation?
A: We usually provide quotes within 24 hours. For urgent requests, please call or note in your email.
AVENTICS electro-pneumatic control valves are ideal for chemical, energy, and smart manufacturing applications requiring high-precision pressure/flow control and long-term stable operation.
