ATOS SDHI-0711 23 High-Efficiency Solenoid-Operated Proportional Valve For Advanced Hydraulic Systems

Technical Specifications

• Model: SDHI-0711 23
• Nominal Size: NG 06
• Valve Configuration: Double solenoid, 3 positions, spring-centered
• Operating Voltage: 24V DC
• Maximum Working Pressure: 350 bar
• Maximum Flow Rate: 60 l/min
• Operating Temperature Range: -20°C to +70°C
• Installation Position: Any position
• Mounting Standard: ISO 4401
• Seal Material: NBR (standard seals), suitable for hydraulic oil
• Weight: Approximately 2.61 lbs

Features

• Direct Operated: The valve is directly operated by solenoids, ensuring precise control.
• Modular Design: Suitable for modular assembly with other ISO 4401 size 06 valves.
• Versatile Applications: Can be used in various hydraulic circuits for directional control, pressure selection, and fast/slow speed controls.
• High Reliability: Built with high-quality materials and tested according to international standards.

Applications

• Machinery and Automation: For precise control of hydraulic fluid in machinery.
• Agricultural and Construction Equipment: Ensuring efficient operation in heavy-duty applications.
• Automotive Systems: Used in hydraulic systems of automobiles.
