Boost Your Productivity With Danfoss OMT200 151B3001 The Best Hydraulic Motor For Your Business

Technical Specifications

• Displacement: 200 cm³/rev
• Shaft Type: Cylindrical, 40 mm diameter with parallel key A12 x 8 x 70 mm (DIN 6885)
• Flange Type: European 4-hole flange
• Port Size: G 3/4 BSP
• Drain Port: G 1/4 BSP
• Maximum Continuous Speed: 625 rpm
• Maximum Intermittent Speed: 750 rpm
• Maximum Continuous Torque: 590 Nm
• Maximum Intermittent Torque: 710 Nm
• Maximum Continuous Pressure: 200 bar
• Maximum Continuous Flow: 125 l/min
• Weight: 21.0 kg
• Dimensions: Length 233 mm, Width 160 mm, Height 170 mm

Features

• High Torque Capability: Provides high torque at relatively low speeds, making it ideal for heavy-duty applications.
• Smooth Operation: Ensures smooth operation at low speeds.
• Robust Design: Built to withstand rough operating conditions, such as high pressure and frequent reversals.
• Tapered Roller Bearings: The output shaft is equipped with tapered roller bearings, making the motor suitable for absorbing static and dynamic radial loads.
• High Efficiency: Hydraulic and mechanical losses are minimized, resulting in high efficiency even at high pressures.
• Versatile Applications: Suitable for a wide range of industrial and mobile hydraulic systems.

Applications

• Agricultural Machinery: For applications requiring high torque and reliability.
• Construction Equipment: Suitable for heavy-duty construction machinery.
• Material Handling: Ideal for forklifts and other lifting equipment.
• Forestry Equipment: Used in forestry machinery for heavy-duty operations.
• Lawn and Turf Equipment: Suitable for landscaping and maintenance machinery.
• Marine Equipment: Suitable for marine applications.

Additional Information

• Accessories: Seal Kit (151B0113) is available as an accessory.
• Customization Options: The motor can be customized with options such as speed sensors, Viton shaft seals, and paint.
