Danfoss OMT500T 151B3062 The Hydraulic Motor That Delivers Exceptional Performance In Demanding Applications

Technical Specifications

• Displacement: 500 cm³/rev
• Shaft Type: Straight shaft with a diameter of 40 mm
• Flange Type: Special flange with tacho connection
• Port Size: G 3/4 BSP
• Drain Port: G 1/4 BSP
• Maximum Continuous Speed: 240 rpm
• Maximum Intermittent Speed: 285 rpm
• Maximum Continuous Torque: 1080 Nm
• Maximum Intermittent Torque: 1260 Nm
• Maximum Continuous Pressure: 200 bar
• Maximum Intermittent Pressure: 240 bar
• Maximum Flow Rate: 125 l/min
• Weight: Approximately 23.0 kg
• Dimensions:
  • Length: 259 mm
  • Width: 160 mm
  • Height: 170 mm

Features

• High Torque Capability: Provides high torque at relatively low speeds, making it ideal for heavy-duty applications.
• Smooth Operation: Ensures smooth operation at low speeds.
• Robust Design: Built to withstand rough operating conditions, such as high pressure and frequent reversals.
• Tapered Roller Bearings: The output shaft is equipped with tapered roller bearings, making the motor suitable for absorbing static and dynamic radial loads.
• High Efficiency: Hydraulic and mechanical losses are minimized, resulting in high efficiency even at high pressures.
• Versatile Applications: Suitable for a wide range of industrial and mobile hydraulic systems.

Applications

• Construction Equipment: Suitable for heavy-duty construction machinery.
• Agricultural Machinery: For applications requiring high torque and reliability.
• Material Handling: Ideal for forklifts and other lifting equipment.
• Forestry Equipment: Used in forestry machinery for heavy-duty operations.
• Lawn and Turf Equipment: Suitable for landscaping and maintenance machinery.
