Efficiency and Reliability The Bosch Rexroth 0510425043 Hydraulic Pump for Industrial Applications

Efficiency and Reliability The Bosch Rexroth 0510425043 Hydraulic Pump for Industrial Applications
Efficiency and Reliability The Bosch Rexroth 0510425043 Hydraulic Pump for Industrial Applications Efficiency and Reliability The Bosch Rexroth 0510425043 Hydraulic Pump for Industrial Applications Efficiency and Reliability The Bosch Rexroth 0510425043 Hydraulic Pump for Industrial Applications

Large Image :  Efficiency and Reliability The Bosch Rexroth 0510425043 Hydraulic Pump for Industrial Applications

Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Certification: cc
Model Number: 0510425043
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: RMB/100-10000/PC
Packaging Details: wooden case/carton
Delivery Time: 3 work days
Payment Terms: T/T
Supply Ability: 10PCS/days
Contact Now

Efficiency and Reliability The Bosch Rexroth 0510425043 Hydraulic Pump for Industrial Applications

Description
After Warranty Service: Video Technical Support Swept Volume: 19/34ml/r
Working Viscosity: 16 ~ 25 Mm²/s Working Pressure: 21Mpa
Weight: 2 - 30 Kg Showroom Location: None
Packing: Wood Package Ports: SAE, BSP, NPT
Highlight:

rexroth hydraulic gear pump

,

rexroth mechanical hydraulic pump

,

industrial hydraulic gear pump

Efficiency and Reliability The Bosch Rexroth 0510425043 Hydraulic Pump for Industrial Applications
Product Specifications
Attribute Value
After Warranty Service Video technical support
Swept Volume 19/34ml/r
Working Viscosity 16 ~ 25 mm²/s
Working Pressure 21Mpa
Weight 2 - 30 kg
Packing Wood Package
Ports SAE, BSP, NPT
Product Overview

The Bosch Rexroth 0510425043 is a high-performance hydraulic gear pump designed for various industrial applications. This pump is part of the AZPF series, known for its reliability and efficiency in demanding environments.

Technical Specifications
  • Model: AZPF-12-008RHO30KB
  • Displacement: 8 cm³ per revolution
  • Maximum Operating Pressure: 280 bar
  • Maximum Intermittent Pressure: 280 bar
  • Maximum Rotational Speed: 4000 RPM
  • Minimum Rotational Speed: 700 RPM
  • Minimum Speed at Maximum Pressure: 1000 RPM
  • Body Dimensions: 92.5 x 87 x 112 mm
  • Shaft Configuration: Conical 1:8
  • Direction of Rotation: Clockwise
  • Front Cover: Rectangular flange with a diameter of 36.47 mm (M8)
  • Material: Aluminum housing
  • Seal Material: NBR (nitrile rubber)
  • Fluid Temperature Range: -15°C to +80°C
  • Recommended Fluid: Mineral oil
  • Recommended Viscosity: 10 mm²/s to 300 mm²/s
Key Features and Benefits
High Efficiency

Ensures efficient operation and long service life.

Robust Construction

Designed for long-term reliability in demanding industrial environments.

Low Noise Operation

Features low working noise and low pulse flow for noise-sensitive applications.

Extended Service Life

Utilizes sliding bearings and gap sealing for durability.

Wide Operating Range

Suitable for various viscosities and speeds.

Industrial Applications
  • Hydraulic Systems: Constant displacement and high pressure systems
  • Material Handling Equipment: Forklifts and pallet trucks
  • Construction Machinery: Excavators and loaders
  • Agricultural Equipment: Tractors and combines
Efficiency and Reliability The Bosch Rexroth 0510425043 Hydraulic Pump for Industrial Applications 0
Frequently Asked Questions
Q: Do you accept small orders?

A: Yes, we accept small orders. Please contact us for details.

Q: Can you ship to my country?

A: Yes, we can ship worldwide. We can assist with logistics if needed.

Q: What are your payment terms?

A: We accept T/T, LC at sight, or 100% full payment.

Q: What is your production lead time?

A: Typically 15 days for MOQ quantities, depending on product and order size.

Q: When can I get a quotation?

A: We provide quotes within 24 hours of inquiry. Urgent requests can be prioritized.
