PPFB-LAN SUN Hydraulic Cartridge Valve High Safety 100% New Original

PPFB-LAN SUN Hydraulic Cartridge Valve High Safety 100% New Original
PPFB-LAN SUN Hydraulic Cartridge Valve High Safety 100% New Original PPFB-LAN SUN Hydraulic Cartridge Valve High Safety 100% New Original

Large Image :  PPFB-LAN SUN Hydraulic Cartridge Valve High Safety 100% New Original

Product Details:
Place of Origin: America
Brand Name: SUN
Certification: cc
Model Number: PPFB-LAN
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: RMB/100-10000/PC
Packaging Details: wooden case/carton
Delivery Time: 3 work days
Payment Terms: T/T
Supply Ability: 10PCS/days
Contact Now

PPFB-LAN SUN Hydraulic Cartridge Valve High Safety 100% New Original

Description
Seal Material: Nitrile, Viton, Or Teflon Port Configuration: Side Port, End Port, Top Port
Mounting: IN LINE Product Type Leakage Rate: Less Than 1 Drop Per Minute
Operating Temperature: Up To 250°F Port Type: NPTF
Adjustment: 5 Fluid Compatibility: Mineral-based Hydraulic Fluids
Highlight:

hydraulic cartridge valve High Safety

,

SUN cartridge relief valve

,

PPFB-LAN

PPFB-LAN SUN Hydraulic Cartridge Valve High Safety 100% New Original
Product Specifications
Attribute Value
Seal Material Nitrile, Viton, or Teflon
Port Configuration Side Port, End Port, Top Port
Mounting IN LINE Product type
Leakage Rate Less than 1 drop per minute
Operating Temperature Up to 250°F
Port Type NPTF
Adjustment 5
Fluid Compatibility Mineral-based hydraulic fluids
Pilot Control Direct operated
Mounting Type Cartridge
Precision ≤5%
Weight 0.9 kg
Model PPFB-LAN
Pressure Rating Up to 5000 PSI
Capacity 10 gpm
Product Features
  • Structural Design: Floating design allows for higher installation torques to prevent loosening or oil leakage
  • Fluid Performance: Center thread layout maximizes flow capacity and reduces eccentricity impact
  • Maintenance: Valve body can be replaced without disassembling pipe joints, reducing downtime
  • Durability: Heat-treated and precision-machined internal components for wear resistance
  • Versatility: Suitable for engineering machinery, ships, mining, and other industrial applications
PPFB-LAN SUN Hydraulic Cartridge Valve High Safety 100% New Original 0
Installation & Maintenance Guidelines
  • Ensure internal thread of socket is complete before installation
  • Align control cover with oil port locating pin during installation
  • Use high-strength screws (grade 10.9 or 12.9) for fixing
  • Regularly check seal integrity and replace if stored for extended periods
  • For high temperature applications, select EPDM sealing ring models (marked with "E")
Note: Selection must be based on specific model parameters and working conditions. Ensure cartridge valve and socket are properly matched.
Frequently Asked Questions
Q: Do you accept small orders?
A: Yes, we accept small orders. Please contact us for details.
Q: Can you ship to my country?
A: Yes, we can arrange shipping worldwide. We can assist with logistics if needed.
Q: What are your payment terms?
A: We accept T/T, LC at sight, and 100% full payment.
Q: What is your production lead time?
A: Typically 15 days for MOQ quantities, depending on product and order size.
Q: When can I get a quotation?
A: We usually provide quotes within 24 hours. Urgent requests can be prioritized.
