Parker PAVC10038R4222 Hydraulic Pump - 100 cm³/rev High Flow Two-Piece Design

Parker PAVC10038R4222 Hydraulic Pump - 100 cm³/rev High Flow Two-Piece Design
Parker PAVC10038R4222 Hydraulic Pump - 100 cm³/rev High Flow Two-Piece Design Parker PAVC10038R4222 Hydraulic Pump - 100 cm³/rev High Flow Two-Piece Design Parker PAVC10038R4222 Hydraulic Pump - 100 cm³/rev High Flow Two-Piece Design Parker PAVC10038R4222 Hydraulic Pump - 100 cm³/rev High Flow Two-Piece Design

Large Image :  Parker PAVC10038R4222 Hydraulic Pump - 100 cm³/rev High Flow Two-Piece Design

Product Details:
Place of Origin: America
Brand Name: Parker
Certification: CC
Model Number: PAVC10038R4222
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: RMB/100-1000/PC
Packaging Details: Wooden Boxes
Delivery Time: 3Days
Payment Terms: T/T
Supply Ability: 10PC/DAY
Contact Now

Parker PAVC10038R4222 Hydraulic Pump - 100 cm³/rev High Flow Two-Piece Design

Description
Supply Voltage: 24 VDC Speed Range: 700-125RPM
New: Yes 100% New Maximum Flow Rate: Standard
Valve Body Material: Cast Iron Power: 159KW
Highlight:

PAVC10038R4222 Parker Hydraulic Pump

,

Two-Piece Parker Hydraulic Pump

,

Multiple Control Parker Hydraulic Pump

PAVC10038R4222 Parker Hydraulic Pump

High flow two-piece design hydraulic pump with multiple control modes and sealed shaft bearing for industrial applications.

Key Specifications
Attribute Value
Supply Voltage 24 VDC
Speed Range 700-125 RPM
Condition 100% New
Maximum Flow Rate Standard
Valve Body Material Cast iron
Power 159 KW
Product Overview

The Parker PAVC10038R4222 is a medium pressure axial piston pump from Parker Hannifin's PAVC100 series, renowned for reliability in industrial applications.

Technical Specifications
  • Displacement: 100 cm³/rev
  • Flow: 179.8 L/min at 1800 rpm
  • Working pressure: up to 248 bar
  • Maximum speed: 2600 rpm
  • Power: 71.2 kW
  • Dimensions: 42 cm × 25 cm × 31 cm
Design Features
  • High-strength cast iron casing with built-in supercharger
  • Two-piece structure for easy maintenance
  • Plug-in control for on-site replacement
  • Replaceable bronze composite valve plate
  • Dynamic pressure cylinder bearing
  • Air release valve for efficient startup
Applications
  • Construction machinery (excavators, loaders)
  • Steel mills (rolling mills, continuous casting machines)
  • Power plant lubrication and cooling systems
  • Marine hydraulic systems (ships, port equipment)
  • Injection molding machines
  • Mining equipment (crushers, loaders)
  • Industrial production line actuators
Performance Advantages
  • High displacement (100 cm³/rev) and flow (179.8 L/min)
  • High pressure capability (248 bar maximum)
  • High speed performance (up to 2600 rpm)
  • Multiple control modes for different working conditions
  • Water glycol liquid compatibility for fire safety
  • Load sensing function for energy efficiency
  • Low noise design for quieter operation
Manufacturer Information
  • Brand: Parker
  • Model: PAVC10038R4222
  • Color: Silver
  • Origin: America
  • Material: Cast Iron
  • Power Source: Electric
