PAVC10038R4222 Parker Hydraulic Pump High Flow Two-Piece Design Multiple Control Modes Sealed Shaft Bearing

The PAVC10038R4222 is a medium pressure axial piston pump from Parker Hannifin's PAVC100 series, renowned for reliability in industrial applications. With a displacement of 100 cm³/rev and flow rate of 179.8 L/min at 1800 rpm, this pump delivers exceptional performance with working pressures up to 248 bar and speeds reaching 2600 rpm.

• High-strength cast iron casing with built-in supercharger
• Two-piece design for easy maintenance and part replacement
• Sealed shaft bearing ensures stable high-pressure operation
• Replaceable bronze composite valve plate enhances durability
• Dynamic pressure cylinder bearing improves performance and lifespan
• Multiple control modes including pressure-compensated and electro-hydraulic proportional
• Water glycol liquid compatibility for high fire-risk environments
• Load sensing capability reduces energy waste
• Low noise design for quieter operation

This hydraulic pump is ideal for demanding industrial applications including:

• Construction machinery (excavators, loaders)
• Steel mill equipment (rolling mills, continuous casting machines)
• Power plant lubrication and cooling systems
• Marine hydraulic systems (steering gears, cranes)
• Injection molding machines
• Mining equipment (crushers, loaders)
• Industrial production line actuators

• Displacement: 100 cm³/rev
• Flow Rate: 179.8 L/min at 1800 rpm
• Working Pressure: Up to 248 bar
• Speed Range: Up to 2600 rpm
• Power: 71.2 kW
• Dimensions: 42 cm × 25 cm × 31 cm
• Material: Cast iron
• Color: Silver
