Rexroth A10VSO45DFR1 32R-VPB12N00-S2655 Mechanical Hydraulic Pump Designed for Heavy Duty Applications

Detailed Specifications

• Displacement: 45 cm³ per revolution.
• Nominal Pressure: 280 bar.
• Maximum Pressure: 350 bar.
• Maximum Speed: 1500 RPM.
• Flow: Up to 67 liters per minute.
• Power: Approximately 55 kW.
• Torque: 200 Nm.
• Control Device: DR F controller X-T open 32/53.
• Circuit Type: Open circuit.
• Shaft End: ISO shaft key.
• Mounting Flange: ISO 3019-2 (metric), 2-hole.
• Service Ports: B flange metric, S flange metric.
• Through Drive: Without through drive.
• Weight: 32.6 kg.

Features

• Optimized for Medium Pressure: Suitable for high-power machines.
• High Power-to-Weight Ratio: Ensures efficient performance in compact designs.
• Quiet Operation: Low noise levels make it suitable for diverse environments.
• Versatile Control Options: Multiple control types available.
• Short Control Response Time: Enhances system responsiveness.
• Universal Through-Drive: Allows for the installation of additional pumps (optional).

Applications

• Construction machinery (e.g., excavators, cranes).
• Agricultural and forestry equipment.
• Industrial manufacturing (e.g., molding machines, press machines).
• Marine and offshore equipment.

Additional Information

• Manufacturer: Bosch Rexroth.
• Material Number: R902452707.
