High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany

High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany
High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany

Large Image :  High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany

Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Certification: cc
Model Number: A10VSO71DRS 32RVPB22U99-S2183
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: RMB/100-10000/PC
Packaging Details: wooden case/carton
Delivery Time: 3 work days
Payment Terms: T/T
Supply Ability: 10PCS/days
Contact Now

High Pressure Oil Usage Mechanical Hydraulic Pump Rexroth A10VSO71DRS 32RVPB22U99-S2183 For Construction Machinery From Germany

Description
Ports: SAE, BSP, NPT Application: Hydraulic Pump
Description: Hydraulic Element Durability: High
Direction Of Rotation: Clockwise Rotation Frequency: 50Hz
Highlight:

Construction Machinery Hydraulic Pump

,

Mechanical Hydraulic Pump A10VSO71DRS

,

32RVPB22U99-S2183 Hydraulic Pump

Rexroth A10VSO71DRS 32RVPB22U99-S2183 Hydraulic Pump
Product Attributes
Attribute Value
Material Cast Iron
Local Service Location None
Shipping Date Within 3 Days After Payment
Payment TT
Standard Or Nonstandard Standard
The A10VSO71DRS 32R-VPB22U99-S2183 is a medium-pressure axial piston variable displacement pump from Bosch Rexroth, designed for high-power machines and industrial applications. Below are the detailed specifications and features based on the search results:

Detailed Specifications

  • Displacement: 71 cm³ per revolution.
  • Nominal Pressure: 280 bar.
  • Maximum Pressure: 350 bar.
  • Maximum Speed: 1800 RPM.
  • Flow Range:
    • Maximum flow: 128 liters per minute.
    • Minimum flow: 0 liters per minute.
  • Control Type: Pressure control.
  • Circuit Type: Open circuit.
  • Shaft End: Parallel shaft with keyway (DIN 6885).
  • Mounting Flange: ISO 2-hole flange.
  • Service Ports: Opposite side ports, metric mounting screws.
  • Through Drive: Without through drive.
  • Weight: Approximately 47 kg.

Features

  • Variable Displacement: The pump can adjust its displacement from 0 to 71 cm³ per revolution, allowing for precise control of flow.
  • Low Noise Level: Optimized for quiet operation, making it suitable for diverse environments.
  • High Functional Reliability: Ensures long service life and high reliability.
  • Short Control Time: Enhances system responsiveness.
  • Versatile Controller Range: Multiple control options available.

Applications

This pump is suitable for a wide range of applications, including:
  • Construction Machinery: Excavators, cranes, and other heavy equipment.
  • Agricultural and Forestry Equipment: Tractors, harvesters, and forestry machines.
  • Industrial Manufacturing: Molding machines, press machines, and other industrial applications.
  • Marine and Offshore Equipment: Hydraulic drives for marine applications.
If you need further information or specific details, please let me know!
