Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00

Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00
Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00 Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00 Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00 Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00 Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00

Large Image :  Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00

Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Certification: cc
Model Number: EA10VSO28DFR1 31R-PPA12N00
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: RMB/100-10000/PC
Packaging Details: wooden case/carton
Delivery Time: 3 work days
Payment Terms: T/T
Supply Ability: 10PCS/days
Contact Now Chat Now

Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00

Description
Ports: SAE, BSP, NPT Application: Hydraulic Pump
Description: Hydraulic Element Durability: High
Direction Of Rotation: Clockwise Rotation Frequency: 50Hz

Rexroth RexrothEA10VSO28DFR1 31R-PPA12N00N00Hydraulic Pump
Product Attributes
Attribute Value
Material Cast Iron
Local Service Location None
Shipping Date Within 3 Days After Payment
Payment TT
Standard Or Nonstandard Standard
The EA10VSO28DFR1 31R-PPA12N00 is a medium-pressure axial piston variable displacement pump from Bosch Rexroth, designed for a wide range of industrial and mobile hydraulic applications. Below are the detailed specifications and features based on the search results:

Detailed Specifications

  • Displacement: 28 cm³ per revolution.
  • Nominal Pressure: 210 bar.
  • Maximum Pressure: 250 bar.
  • Maximum Speed: 3200 RPM.
  • Flow Range:
    • Maximum flow: 90 liters per minute.
    • Minimum flow: 0 liters per minute.
  • Control Type: Pressure control.
  • Circuit Type: Open circuit.
  • Shaft End: Parallel shaft with keyway.
  • Mounting Flange: ISO 2-hole flange.
  • Service Ports: Opposite side ports, metric mounting screws.
  • Through Drive: Available.
  • Weight: Approximately 11.5 kg.

Features

  • Variable Displacement: The pump can adjust its displacement from 0 to 28 cm³ per revolution, allowing for precise control of flow.
  • Low Noise Level: Optimized for quiet operation, making it suitable for diverse environments.
  • High Functional Reliability: Ensures long service life and high reliability.
  • Short Control Time: Enhances system responsiveness.
  • Versatile Controller Range: Multiple control options available.

Applications

The EA10VSO28DFR1 31R-PPA12N00 is suitable for a wide range of applications, including:
  • Construction Machinery: Excavators, cranes, and other heavy equipment.
  • Agricultural and Forestry Equipment: Tractors, harvesters, and forestry machines.
  • Industrial Manufacturing: Molding machines, press machines, and other industrial applications.
  • Marine and Offshore Equipment: Hydraulic drives for marine applications.
If you need further information or specific details, please let me know!

Industrial Mechanical Hydraulic Pump With And Efficiency Durable Cast Iron Material Rexroth EA10VSO28DFR1 31R-PPA12N00N00 0
Frequently Asked Questions
Do you accept small orders?

Yes, we accept small orders. Please contact us for details.

Can you ship to my country?

Yes, we can arrange shipping worldwide. We can assist with logistics if needed.

What are your payment terms?

We accept T/T, LC at sight, or 100% full payment.

What is your production lead time?

Typically 15 days for MOQ quantities, depending on product and order size.

When can I get a quotation?

We provide quotes within 24 hours of inquiry. Urgent requests can be prioritized.
