Festo AEVU-20-10-P-A Oil Cylinder 20mm Piston Diameter 10mm Stroke Single-Acting Elastic Cushioning 1-10 Bar Operating Pressure

Product Overview

• Model: AEVU-20-10-P-A
• Brand: Festo

Technical Specifications

• Piston Diameter: 20 mm
• Stroke: 10 mm
• Operating Mode: Single-acting (spring-return)
• Cushioning: Elastic cushioning rings/plates at both ends
• Mounting Position: Any position
• Operating Pressure Range: 1 to 10 bar
• Operating Temperature Range: -20°C to 80°C
• Theoretical Force at 6 bar: 180 N
• Weight: 176.44 g
• Pneumatic Connection: M5
• Materials:
  • Cylinder Housing: Extruded aluminum alloy
  • Piston Rod: High-alloy stainless steel
  • Seals: NBR, TPE-U (PU)

Features

• Compact Design: Suitable for applications with limited space.
• Integrated Magnet: Ready for position sensing with proximity switches.
• Versatile Mounting: Can be installed in any position.
• Smooth Operation: Elastic cushioning rings/plates at both ends provide smooth and quiet operation.
